Android Auto Radio Carplay Citroen C4 2010 - 2019

Android Auto Radio Carplay Citroen C4 2010 - 2019

Enhance your Citroen C4 (2010-2019) with this advanced Android multimedia system. Designed to integrate seamlessly into your vehicle, this equipment offers a more connected and safer driving experience thanks to its multiple functions.

• Full connectivity : Enjoy Apple CarPlay and Android Auto both wirelessly and via cable. Transfer all the content from your mobile to the car screen with Mirror Link. Listen to your favorite music and playlists on Spotify, and navigate with ease using Google Maps or Waze via voice commands.
• Keep the original functions : Don't worry about losing the steering wheel controls or the car's fuel consumption or journey information. From the screen you can control all those essential functions that you don't want to lose when installing an Android radio.
• Technical specifications :
  • Operating system : Android 12
  • Touch Screen : 10 inches (1024x600) [1280x720 optional Octa version]
  • Processor : Quad Core 1.2 GHz [Octa Core 1.8 GHz optional Octa version]
  • RAM Memory : 1GB DDR3 [2GB/4GB/6GB/8GB optional]
  • Internal storage : 32GB [64GB/128GB/256GB optional]
  • Connectivity : Bluetooth, WIFI [4G network optional Octa version]
  • Built-in GPS
  • Mirror Link Functionality
  • Integrated steering wheel control
  • Radio with RDS + DSP

Transform your Citroen C4 with this Android multimedia screen and enjoy a more efficient, safe and connected driving experience.

CONTENT OF THE KIT:

• Screen, custom frame, power cable, USB cable, GPS module, rear camera cable, antenna cable, CANBUS module (if the model has CANBUS), 4G antenna (Octa version only) and RCA wiring with SIM card slot (Octa version only) .

The OCTA variants are our most economical options, they have a 4-core processor, a resolution of 1024*600, RDS, GPS connectivity, Wi-Fi, Bluetooth and wireless Android Auto & Apple CarPlay systems. These variants do not support reversing cameras with 1080P resolution.

The OCTA variants have an 8-core processor, 1280*720 HD resolution, GPS connectivity, Wi-Fi, Bluetooth, 4G (inserting a SIM card) RDS, GPS connectivity, Wi-Fi, Bluetooth, Android Auto & Apple systems Wireless CarPlay, additional RCA wiring with SIM card slot and DSP equalizer options.

CANBUS Configuration (for vehicles with CANBUS)

Make sure the CANBUS module is properly connected:

Quad :

Enter the Car Settings application, Factory section , CarType Configuration , password 000000 / 16176699 , select the canbus brand and car model

Octa :

Enter the Car Settings application, Factory section , CarType Configuration , password 000000 / 8888 , select the canbus brand and car model

Steering wheel control configuration (for vehicles WITHOUT CANBUS)

Quad :

Make sure that no CANBUS configuration has been previously applied by going to Car Settings , Factory section , CarType Configuration , password 000000 / 16176699 , check that no option is selected, then go to General , SWC and leave it on Learning

After this go into Car settings , Factory section , Learning physical keys and configuring the controls to your liking

Depending on the software, the last step may be to enter the SW Learning application to configure the controls to your liking.

Octa :

Make sure that no CANBUS configuration has been previously applied by going to Car Settings , Factory section , CarType Configuration , password 000000 / 8888 , check that no option is selected, then go to General , SWC and leave it on Learning

After this go into Car settings , Factory section , Learning physical keys and configuring the controls to your liking

Depending on the software, the last step may be to enter the KeyStudy application to configure the controls to your liking.

Rear Camera Connection

VEHICLES WITH CANBUS

* THE ⓸ CABLE IS LOCATED IN THE MAIN WIRING HARNESS OF THE RADIO, IN SOME MODELS IT IS USUALLY LABELED AS "REVERSE" OR "BRAKE" . IF IT IS NOT LABELED, IT IS MARKED IN THE FOLLOWING PHOTO AS ⓷ .

VEHICLES WITHOUT CANBUS

* THE ⓸ CABLE IS LOCATED IN THE MAIN WIRING HARNESS OF THE RADIO, IN SOME MODELS IT IS USUALLY LABELED AS "REVERSE" OR "BRAKE" . IF IT IS NOT LABELED, IT IS MARKED IN THE FOLLOWING PHOTO AS ⓷ .

Rear Camera Settings

Quad :

Go to Settings , Factory , Password 000000 , Reverse Detection.

Octa :

Go to Settings , Car Infotainment , About device , click on the gear at the top right , password 8888 or 8878 , Backar Setup , look for CamType and select the appropriate option for our camera
